FD25 Diesel Fork Lifter with Lift Height 3000-5000mm Forklift Container Lifter

Model NO. : FD25

Lift height : 3000~5000mm

Condition : New

Free Lifting Height : 135mm

Fork Size : 1070*122*40mm

Mast Tilt Angle : 6/12 Degree

Min. Ground Clearance : 110mm

Overhead Guard Height : 2090mm

Front Overhang : 473mm

Height From Seat to Overhead Guard : 1005mm

Transport Package : Nude Package

Trademark : SNSC

Origin : China

HS Code : 84270290

Supply Ability : 500/Months

Cab Location : Not Adjustable

Type : Diesel Forklift

Power : Diesel Engine

Load Capacity : 1T - 5T

Fuel : Diesel

Load center : 500mm

Customization : Available | Customized Request

Place of Origin : china

Brand Name : snsc

Certification : CE/ISO

MOQ : 1 unit

Price : negotiable

Packaging Details : shipped by container

Delivery Time : 30-45 Days

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Contact Now

SNSC 2.5 Ton warehouse diesel forklift truck for sale
FD25 Diesel Fork Lifter with Lift Height 3000-5000mm Forklift Container Lifter
FD25 Diesel Fork Lifter with Lift Height 3000-5000mm Forklift Container Lifter
FD25 Diesel Fork Lifter with Lift Height 3000-5000mm Forklift Container Lifter
FD25 Diesel Fork Lifter with Lift Height 3000-5000mm Forklift Container Lifter
FD25 Diesel Fork Lifter with Lift Height 3000-5000mm Forklift Container Lifter


Details:
Japan Mitsubishi Engine;
Japan SHIMADZU Hydraulic System(including pumps and valves and oil pipes);
3m mast;
With Side Shifter
Electric Hydraulic Automatic Transmission by TCM technology;
Lamp protection;
Triangle wide view back mirror;
Waterproof overhead guard;
Backing buzzer and warning light;
Double Front Pneumatic Tires

Common Options:
Solid Tires;
3m-7m duplex or triplex full free mast;
Attachments such as paper roll clamp, block clamp, bale clamp, bucket, etc;
Fully closed cabin with heater or air conditioner;
Side shifter and fork positioner;
Fully suspension luxury seat;
Double filter;
High exhaust;
Customized color except green, red and orange.

Specifications:
Specifications Unit FD25
Features Power type Diesel
Rated load kg 2500
Load center mm 500
Lifting height mm 3000
Free lifting height mm 135
Fork size L*W*T mm 1070*122*40
Mast tilt angle Front/Rear . 6/12
Min. turning radius mm 2240
Min.ground clearance Mast mm 110
Overhead guard height mm 2090
Front overhang mm 473
Performance Max. travelling speed loaded km/h 19
Max. lifting speed loaded/empty mm/s 490/510
Max. traction force loaded KN 17
Max. climbing ability % 20
Dimension Overall length without fork mm 2570
Overall width mm 1160
Mast lowered height mm 1990
Mast extended height mm 4000
Chassis Tyre Front 7.00-12-12PR
Rear 6.00-9-10PR
Wheel base mm 1600
Wheel thread Front/Rear mm 970/970
Weight(without load) kg 3800
Powertrain Battery V/AH 12/90
Engine Model XC490BPG
Rated power km/r.p.m 37/2650
Rated torque Nm/r.p.m 148/2000
No. cylinder 4
Bore x stroke mm 90X100
Displacement L 2.54
Fuel tank capacity L 60
Transmission/shift 1/1 automatic transmission
Operation pressure Mpa 17.5

Details of 2.5Ton Diesel Forklift FD25
FD25 Diesel Fork Lifter with Lift Height 3000-5000mm Forklift Container Lifter
FD25 Diesel Fork Lifter with Lift Height 3000-5000mm Forklift Container Lifter
FD25 Diesel Fork Lifter with Lift Height 3000-5000mm Forklift Container Lifter
FD25 Diesel Fork Lifter with Lift Height 3000-5000mm Forklift Container Lifter
2.5Ton Diesel Forklift Common Optionals:
Side shifter,Double front tires,Solid tire,Double air filter,Vertical exhaust,fork extension,Cab,Fork positioner, duplex/ triplex full free mast

Forklift Catalogue:
Diesel Forklift capacity is from 1.5 ton diesel forklift to 10 ton diesel forklift;
(FD15/FD20/FD25/FD30/FD35/FD40/FD45/FD50/FD60/FD70/FD80/FD100)
Electric Forklift capacity is from 1.5ton battery forklift to 3.5ton battery forklift;
(FB15/FB20/FB25/FB30/FB35)
LPG&Gasoline Forklift capacity is from 1.5ton LPG forklift to 3.5ton LPG forklift;
(FL15/FL20/FL25/FL30/FL35)
Wearhouse material handling equipments include Electric Pallet Truck (TB)/Electric Stacker(DB)/ Electric Reach Truck(YB)/Electric Tractor(QB).
FD25 Diesel Fork Lifter with Lift Height 3000-5000mm Forklift Container Lifter
Company Introduction:
We, SNSC, are top quality forklift manufacture in China, with 130,000 square meters production area, 30,000 units production capacity per year,5000 sets export volume.

We regarde "Quality product, reasonable price, efficient production time and good after-sale servie" as our tenet."

We hope to cooperate with more customers for mutual development and benifits. Welcome to contact us with your demands.
